Joerns Healthcare Oxford Easytrack FS Gantry (Free standing)
Price of this part: £0.00
Price of this part: £0.00
Price of this part: £0.00
Price of this part: £0.00
Lightweight, Free-Standing Portable Gantry
- Quick and easy to assemble by a single person
- Simple, no tools design
- Large safe working load of 200kg / 31st
- Lightweight components
- Easy to transport and store
Joerns Healthcare Oxford Easytrack FS Gantry (Free standing)
The Easytrack FS Gantry is a free standing, overhead portable tracking system, that is based on many of the same principles as the standard Easytrack range and designed to be paired with the Oxford Voyager Hoist.
However, it does not rely on support from the ceiling, thereby removing any potential structural issues that may be encountered.
The Easytrack systems are unique temporary/semi-permanent overhead tracking systems designed for use with the Oxford Voyager Portable hoist.
This functionality ensures this suite of products is ideal for clients residing in rental accommodation, where there is no permit for structural changes.
This is easy to transport and store away.
In addition, it has a safe working load of 200kg/440lbs/31st to match the Voyager Portable motor.
An extending top rail ensures a transfer span of almost 3m is possible, comfortably supporting bed to chair or bed to commode transfers within a room. The spring-loaded, upright posts can also be extended. Helping to improve obstacle and furniture clearance and support transfers on to a variety of surface types and heights.
A further benefit of the voyager lift system and a direct result of its simple and intuitive design, is that installers do not require the complex knowledge necessary to specify and install fixed lift systems.
Downloads
Ceiling Lifts Brochure
Sling Guide
Easytrack FS User Guide
Portable Gantry Hoist Easytrack FS Main Features
- Quick and easy to assemble by a single person
- Simple, no tools design
- Large safe working load of 200kg / 31st
- Lightweight components
- Easy to transport and store
We are able to provide a free assessment if required and assessments are subject to area restrictions.
Assessments for private clients subject to area restrictions will be chargeable
Products are not eligible for a free 28 day return if they’ve been used or installed.
(Assessments, Surveys and Installations subject to area restrictions).
VAT exemption (UK only)
There are strict laws governing VAT (Value Added Tax) exemption to registered disabled people in the UK.
Please check with your local VAT office or follow the links from our ARE YOU ELIGIBLE FOR VAT EXEMPTION
NOTE - Specifications may change at the manufacturers discretion.
Any changes will be updated accordingly and no orders will be processed without prior notification.
All orders are subject to Easy Care Systems Ltd Terms and Conditions.
Assessments and site surveys subject to area restrictions.
Specification | Easytrack FS Gantry |
---|---|
Safe Working Load | 200kg / 441Ibs / 31st |
Floor to Top of Rail | 1,830 – 2,406mm (72 – 95”) |
Floor to Bottom of Rail | 1,680 – 2,256mm (66 – 89”) |
Exterior Width | 2,210 – 3,230mm (87 – 127”) |
Interior Width | 1,910 – 2,930mm (75 – 115”) |
Footplate Length | 1,075mm (42”) |
Footplate Width | 150mm (6”) |
Rail Weight | 14kg (31Ibs) |
Post Weight (each) | 9.5kg (21Ibs) |
Footplate | 5.5kg (12Ibs) |
