Joerns Healthcare Oxford Easytrack FS Gantry (Free standing)

VAT Exemption

VAT relief allows chronically sick or disabled people to buy eligible items at 0% rather than 20% VAT. Dont forget to tick the VAT Exempt box in the checkout.

Product SKU: J-VOY-9720010KVAT relief

Price of this part: £0.00

Price of this part: £0.00

Price of this part: £0.00

Price of this part: £0.00

Item in Stock
£1934.00

Lightweight, Free-Standing Portable Gantry

  • Quick and easy to assemble by a single person
  • Simple, no tools design
  • Large safe working load of 200kg / 31st
  • Lightweight components
  • Easy to transport and store
quantity
minus
plus

VAT Exemption

VAT relief allows chronically sick or disabled people to buy eligible items at 0% rather than 20% VAT. Dont forget to tick the VAT Exempt box in the checkout.

Joerns Healthcare Oxford Easytrack FS Gantry (Free standing)
The Easytrack FS Gantry is a free standing, overhead portable tracking system, that is based on many of the same principles as the standard Easytrack range and designed to be paired with the Oxford Voyager Hoist.
However, it does not rely on support from the ceiling, thereby removing any potential structural issues that may be encountered.

The Easytrack systems are unique temporary/semi-permanent overhead tracking systems designed for use with the Oxford Voyager Portable hoist.

This functionality ensures this suite of products is ideal for clients residing in rental accommodation, where there is no permit for structural changes.
This is easy to transport and store away.
In addition, it has a safe working load of 200kg/440lbs/31st to match the Voyager Portable motor.

Joern Oxford Easytrack FS Gantry (Free standing) | Patient transfer | Buy Order Online Easy Care Systems

An extending top rail ensures a transfer span of almost 3m is possible, comfortably supporting bed to chair or bed to commode transfers within a room. The spring-loaded, upright posts can also be extended. Helping to improve obstacle and furniture clearance and support transfers on to a variety of surface types and heights.

A further benefit of the voyager lift system and a direct result of its simple and intuitive design, is that installers do not require the complex knowledge necessary to specify and install fixed lift systems.

Downloads
Ceiling Lifts Brochure
Sling Guide
Easytrack FS User Guide

Portable Gantry Hoist Easytrack FS Main Features

  • Quick and easy to assemble by a single person
  • Simple, no tools design
  • Large safe working load of 200kg / 31st
  • Lightweight components
  • Easy to transport and store

We are able to provide a free assessment if required and assessments are subject to area restrictions.
Assessments for private clients subject to area restrictions will be chargeable
Products are not eligible for a free 28 day return if they’ve been used or installed.
(Assessments, Surveys and Installations subject to area restrictions).

VAT exemption (UK only)
There are strict laws governing VAT (Value Added Tax) exemption to registered disabled people in the UK.
Please check with your local VAT office or follow the links from our ARE YOU ELIGIBLE FOR VAT EXEMPTION

NOTE - Specifications may change at the manufacturers discretion.
Any changes will be updated accordingly and no orders will be processed without prior notification.
All orders are subject to Easy Care Systems Ltd Terms and Conditions.
Assessments and site surveys subject to area restrictions.

SpecificationEasytrack FS Gantry
Safe Working Load200kg / 441Ibs / 31st
Floor to Top of Rail1,830 – 2,406mm (72 – 95”)
Floor to Bottom of Rail1,680 – 2,256mm (66 – 89”)
Exterior Width2,210 – 3,230mm (87 – 127”)
Interior Width1,910 – 2,930mm (75 – 115”)
Footplate Length1,075mm (42”)
Footplate Width150mm (6”)
Rail Weight14kg (31Ibs)
Post Weight (each)9.5kg (21Ibs)
Footplate5.5kg (12Ibs)
